See Your Board — A Built-In Gerber Viewer

A typeCAD build is deterministic — the same code produces byte-identical KiCad files — but “correct” and “looks right” are different things. Zones pour, planes stitch, the autorouter weaves tracks between pads, and until now the only way to actually see the result was to open KiCad and refill zones by hand. The latest release fixes that: @typecad/typecad now ships a built-in Gerber viewer — a parser for RS-274X and Excellon, an SVG renderer, and an interactive board view, all with zero npm dependencies.

Gerbers are the right thing to look at, too. They’re the ground truth of what a fab house will actually make — not a rendering of your source, but the compiled output itself.

One command, one file, your board

Point the new gerber-viewer CLI at any gerber directory — the build/gerbers/ folder typecad export writes, a jlcpcb-export output, or any KiCad fab set:

typecad export gerbers
npx gerber-viewer build/gerbers -o board-view.html --open

You get a single self-contained HTML file — no server, no assets, works over file:// or attached to an email. The layer sidebar lists every copper, mask, paste, silk, edge, and drill file with visibility toggles and per-layer opacity. Wheel zooms about the cursor, drag pans, 0 fits the board, and a readout tracks the cursor in board coordinates. Copper, edge, and drill layers are visible by default; the rest are one click away.

The loop: build → see → change → build

The viewer is more useful as a live companion. In any project created with typecad create you’ll find a gerber_viewer npm script wired to the serve mode:

npm run gerber_viewer    # http://localhost:4273

The dev server watches build/*.kicad_pcb. Every time you run npm run build, it re-exports the gerbers (typecad export gerbers + drill), re-renders the viewer, and live-reloads the open page. Change a component value in code, rebuild, and the board on screen updates — no KiCad launch, no manual export, no browser refresh. Before the first build it shows a “waiting” page that flips to the board the moment one exists.

It reuses the project’s own typecad export under the hood, so KiCad discovery, drill output, and zone-refilled boards all behave exactly as they do everywhere else.

It speaks fab files properly

The parser covers the parts of the Gerber spec real boards actually use: %FS coordinate formats with leading- or trailing-zero omission, all four standard aperture templates, aperture macros with full arithmetic evaluation (thermal-style donut pads from your footprints render correctly), multi-quadrant and single-quadrant arcs including full circles, regions with clear polarity, and X2 attributes. Drill files come in Excellon FMAT-2 flavor — point holes and routed slots.

Layer detection reads %TF.FileFunction first and falls back to filenames — both KiCad’s F_Cu/In2_Cu style and legacy .gtl/.gbo extensions — then orders layers in stackup order with KiCad-like colors, so a 4-layer board looks like a 4-layer board. Anything it doesn’t understand produces a warning, never a crash; a board with an exotic macro still renders with everything else intact.

In code, not just on the CLI

Everything is importable via a subpath export — parse fab files, inspect geometry, or embed rendering in your own tooling:

import { parseGerber, detectLayer, renderSvg } from '@typecad/typecad/gerber-viewer';

const image = parseGerber(fs.readFileSync('board-F_Cu.gbr', 'utf8'));
const layer = detectLayer('board-F_Cu.gbr', image); // copper, front
renderSvg([{ info: layer, image }]); // → SVG string

buildViewerFromFiles runs the whole pipeline — parse, detect, order, render, wrap in the interactive HTML — and startGerberViewerServer exposes the live server for custom dev setups.

Try it

Update to the latest alpha and open any board you’ve already built:

npx @typecad/typecad create   # new projects include the gerber_viewer script
# or in an existing project:
npx gerber-viewer serve

The viewer is part of @typecad/typecad — no extra install, no extra dependencies, nothing new to keep at arm’s length. Build your board, open localhost:4273, and see what your code just made.
